Powerful Engineering Suite
ZWmech is a integrated plug in for ZWCAD and adds a powerful array of engineering modules to both the 2D and 3D to the ZWCAD platform. The ZWmech products include Mechanical, Piping, Structural Steel Detailing, and HVAC applications. All ZWmech products support the latest Windows 7, Windows 8 and Windows 10 - both 32-bit and 64-bit.
ZWmech is now compatible with ZWCAD 2017 to ZWCAD 2022
ZWmech supports all versions of ZWCAD from ZWCAD 2017 to ZWCAD 2022 (Both Classical & Professional versions)
ZWCAD is a powerful CAD software - but you can now add even more power and increase your drawing efficiency and accuracy with the engineering applications: ZWmech. Each ZWmech module is a set of powerful functions and utilities that makes your engineering design and drafting work easy and cost effective. The modules can be purchased separately or as a bundled suite at a discount.
Duct shape options include rectangular, round and flat oval. Features include: auto-BOM, auto-labeling, flat sheet development.... Several Duct and Duct fittings included: Duct bends, transitions, tees & wyes, offsets, branches, dampers, diffusers, flexible duct, grills, build-in & customer defined symbols and many accessories... Read more
