Γνωρίστε το ZWCAD, το σχεδιαστικό πρόγραμμα που σας βοηθά να ετοιμάσετε τα σχέδια σας γρήγορα, εύκολα και με ακρίβεια. Αγοράστε πακέτο δικτυακών αδειών γιατί συμφέρει! Δοκιμάστε το πρόγραμμα στην έκδοση ZWCAD 2024 που μόλις κυκλοφόρησε.
Διαφορές μεταξύ ZWCAD Professional και ZWCAD Standard
To ZWCAD Professional περιλαμβάνει όλες τις λειτουργίες της έκδοσης Standard και ακόμα:
3d modelling and visualisation
To ZWCAD Professional περιλαμβάνει όλες τις λειτουργίες της έκδοσης Standard και ακόμα:
3d modelling and visualisation
- Full ACIS modeling & editing
- Rendering
- Solprof
- Region
- Pointcloud
- ArcGIS
- .NET
- Runtime extension (ZRX/ARX)
- Solution Development System (SDS/ADS)
- Visual Basic for Applications (VBA 32/64bit)
Πόσο καλά γνωρίζεις το ZWCAD;
Κάνε το QUIZ και κέρδισε δώρο δοκιμαστικές εκδόσεις του ZWCAD!
Διαφορές μεταξύ ZWCAD και ACAD
Κυκλοφόρησε το ZWCAD 2024 SP1 !!!
Το σχεδιαστικό πρόγραμμα που αγοράζετε άπαξ και δεν δεσμεύεστε με ενοίκια και πρόσθετα κόστη συντήρησης.
Δοκιμάστε το πρόγραμμα στην έκδοση ZWCAD 2024 SP1 που μόλις κυκλοφόρησε. Η έκδοση αυτή φέρνει μεγαλύτερη ταχύτητα και περισσότερη φιλικότητα με νέες εντυπωσιακές 2D και 3D λειτουργίες και βελτιώσεις.
Αγόρασε/ αναβάθμισε τώρα και πάρε απίθανα δώρα για το γραφείο σου!
Τι νέο θα βρείτε στο ZWCAD 2024 SP1
Efficiency
Regeneration Optimization
Improved the performance when frequent regeneration during drawing viewing caused lag issues, resulting in a twofold increase in efficiency for the "zoom" command.
Enhanced efficiency when opening drawings that contain a large number of nested blocks or nested external references.
Optimized the drawing appearance for circles, arcs, ellipses, elliptical arcs, and arc segments, ensuring that they no longer display as plines segments after multiple zoom operations, significantly improving graphic display quality.
Copyclip&Pasteclip Optimization
We have optimized the "COPYCLIP" and "PASTECLIP" commands, as well as enhanced the efficiency of "COPYBASE," "CUTCLIP," and "WMFOUT."
Efficiency Enhancement for selecting entities with numerous grips
Efficiency has been improved when selecting entities with a large number of grips in drawing.
Stability
We have addressed 147 reproducible stability issues from the Jira database, including:
Fixed the issue where the "Select File" dialog caused CAD to crash when navigating operations.
Resolved the problem where specific drawings became increasingly unresponsive during the save process, leading to unresponsive drawings upon opening.
Fixed the issue where the program crashed when converting dynamic blocks to flexiblock blocks in specific drawings.
Addressed the problem where the program became unresponsive when saving specific drawings in DWG 2000/2004 format.
New Features
Sheet Set Manager Optimization
Sheet Set Manager is a robust tool that combines drawing management with the capability to print drawings. In this version, we have optimized and enhanced itsfunctionality. The following are the newly added features:
Model Views
A new "Model Views" tab has been added, where users can add a designated folder to display a list of views from the model space of drawing files. This enables users to conveniently insert views to the sheet list as external references.
Users can insert model views from different drawings into a specified layout. When inserting views, users have the option to choose the appropriate scale.
Sheet Views
A new "Sheet Views" tab has been added to manage the model views that have been added to the layouts in the sheet set list. Users can also place label blocks and callout blocks on these layouts.
Page Setup Override
The " Page Setup Override" printing mode has been introduced. Users often save page setup templates for various printing scenarios in a DWT file. When a page setup file path is specified within the Sheet Set properties, users can utilize the page setups from the DWT file for printing. This enhances the efficiency of printing layouts in the sheet lists.
Sheet List Table optimization
17 data types have been added when creating a sheet list table so the tables created can contain a broader range of content.
The update function of the table has been added to ensure that the table's data remains up to date when there are modifications. The editing function of the table has been added to allow modifications to the table content, providing users with greater flexibility.
Smart Plot Optimization
The Smart Plot feature assists users in batch printing multiple drawings, significantly enhancing the efficiency of the printing process. In this version, we continue to optimize and improve the functionality of Smart Plot, with the following main improvements:
Plot open drawings
The print output options now include the "Plot open drawings" feature, which allows users to directly plot all drawings that are open in ZWCAD.
Multi-document plot
The print output options now include the "Multi-document plot" feature, which allows users to simultaneously batch print multiple drawings from different folders, significantly improving the efficiency of multiple drawing printing.
The number of selected drawings will be displayed in the dialog, and users can use the "Preview" feature to verify if the correct drawings have been selected before printing.
Paper Size: “Same drawing size”
When selecting the paper size for printing, a new option "Same drawing size" has been added. When you choose the "Same drawing size" option for printing in a model space that contains drawings with different paper sizes, it will automatically recognize and print the drawings with their respective paper sizes.
The "Same drawing size" feature of the current version only supports recognizing standard frame sizes with a 1:1 scale for printing. If it fails to identify a standard frame, it will default to printing in A4 size.
Block Setting: Add dropdown list for block selection
In the Block Setting dialog, a new dropdown list has been added to the “Block name”. Users can associate the block names with relevant print configurations by selecting the appropriate block names.
New Drawing Tools
Concentric circles/ellipses/polygons/rectangles
ZWCAD supports the “Concentric” option when drawing circles/ellipses/polygons/rectangles. With this option, users can easily create a series of concentric circles/ellipses/polygons/rectangles without having to manually draw them one by one, which is very convenient.
Oblique rectangles
ZWCAD supports the “Oblique” option when drawing a rectangle. This enables users to draw rectangles with unusual angles, rather than being limited to traditional horizontal or vertical orientations. This is very important when designing irregular buildings, signs, or other objects with oblique sides.
Symmetric draw
The function of symmetric drawing is supported. Users can quickly draw symmetrical graphics in various ways, including symmetrically, horizontally, or in a custom manner. This helps users reduce repeated drawing work, and improve efficiency and accuracy of drawing symmetrical graphics.
Copyclip&Pasteclip Optimization
A new settings dialog has been added for common copy and paste operations (Copyclip&Pasteclip). Users can customize the CAD images that are copied to the clipboard through this dialog. The Copy and Paste Settings dialog can be accessed through the Ribbon, Classic menu, or command line.
The parameters that users can configure in the dialog are as follows: Copy and paste format
The default paste format is "ZWCAD Drawing Object" and it is unchangeable. However, users can choose other data formats, including "Picture" and "Bitmap." "Picture" belongs to metafiles and can store objects as vector graphics formats, while "Bitmap" belongs to bitmap files and can store objects as raster graphics formats, which is the default image format for Windows OS.
Paste range
Through the settings dialog, users can configure the image boundary type when pasting objects into third-party software. It supports three image boundary types: "Viewport extents", "Drawing limits", and "Drawing limits within viewport extents". "Viewport extents" copies the entire viewport frame, resulting in more whitespace, while "Drawing limits" or "Drawing limits within viewport extents" recognizes the edges of objects and copies them, minimizing the amount of whitespace as much as possible.
Paste color
The settings dialog allows users to configure the image color when pasting objects into other document software. Users can choose to retain the original colors of the objects or change the colors.
Spline Optimization
The spline function is a powerful and flexible tool to draw complex, smooth curves and surfaces for a variety of different design needs. Whether it is for engineering design, architectural design or others, spline is one of the indispensable and important tools. In this version, the function of spline has also been further optimized, aiming to bring convenience and efficiency to designers and engineers from all walks of life.
The specific improvements are as follows:
New features
In this version, helixes, splines and other entities are merged into splines, allowing users to manipulate and draw smooth curves more conveniently. In the process of spline drawing, the “Method” branch is added to indicate two ways of drawing splines: fit points and control vertices.
When the spline is drawn using the fit points method, each point is located on the curve by default, showing a very smooth effect. The newly added “Knots” branch, including three different drawing methods: chord, square root of chord length and uniform, makes the drawing method more flexible.
When the spline is drawn using the control vertices method, except for the endpoints, the other points are not located on the curve, so the direction of the curve can be adjusted by controlling the position of the vertices. In addition, the “Degree” branch has been added and users can directly change the shape of the spline curve and easily realize customized curve effects by adjusting the degree parameters.
The BLEND command has been added. With this command, you can easily create a spline in the gap between two selected lines or curves, making your drawing work more efficient.
Efficiency improvement
The efficiency of the spline function has been significantly improved. When users deal with spline curves with a large number of points, ZWCAD can perform drawing and editing operations more quickly, improving the efficiency and fluency of drawing work. New entries
In addition, to help you use these new functions more conveniently, we have added new entries in the Ribbon or Classic menu, toolbar and quick properties bar. At the same time, relevant information prompts are also provided to make it easier for you to grasp how to use new functions and improve user experience.
Area Optimization
The Area function is usually used to measure and calculate the area of graphic objects and is designed to help users quickly and accurately calculate the area of objects. It is very commonly used in architectural design, land planning, engineering drawing and other fields.
The specific improvements are as follows:
Area preview function
The newly added area preview function is simple and intuitive. When the user selects an object for area calculation, the cursor pick-up box hovers over the object, and the preview effect can be seen quickly and clearly, so the user can confirm if he/she selects the correct area for calculation.
Optimization for calculating the area
Optimization for calculating the area of filled objects
The recognition of edges and hollow areas is more accurate, and the area of these parts is removed from the calculation. At the same time, for the calculation of overlapping parts, the software does not repeat calculations to ensure the accuracy and efficiency of area calculation.
Optimization for calculating the area of spline objects
For spline objects, the area calculation algorithm is further optimized to ensure the accuracy of calculation results.
Trim/Extend Optimization
Both Trim and Extend functions are used to edit and adjust graphic entities and are used frequently in design. They can help designers easily deal with intersections and overlaps between graphic entities, thereby achieving precise graphic editing. The improvements of Trim and Extend are as follows:
Added quick mode
In quick mode, all objects are automatically used as trim edges or boundaries. This means users no longer need to select entities or edges one by one when trimming and extending objects, which simplifies the operation process and is especially suitable for batch processing.
Trim and Extrim are combined so now there are three modes: Quick, Standard and EXmode. By concentrating functions in one place, users can choose different modes according to their actual needs, avoid confusing and memorizing different commands, and improve the convenience of use.
Added enhanced Extend function
Users can now directly click on the side of the entity that needs to be extended, and the operation can be quickly performed without the need to select the entity. By simplifying the workflow, it helps users greatly save time and improve efficiency.
Supported the Extend function for splines
The Extend function for splines is introduced, which expands the application range of the Extend function, enabling users to deal with complex curve entities more flexibly.
Optimized the text trimming method
For text trimming, it now supports trimming by contour lines. This improvement ensures the accuracy and integrity of text trimming, making the results of text processing more precise.
DIST Optimization
The optimization of the DIST function brings a more enjoyable drawing experience for users and helps them improve the accuracy and efficiency of drawing. The specific optimizations are as follows:
Optimization of point calculation after coordinate conversion
The point calculation process after coordinate conversion is optimized to ensure that the arc endpoints can still be picked correctly after converting to the user coordinate system (USC), so that the graphics can be drawn accurately.
UNDO optimization
The effect of UNDO operation is improved to ensure that each undo operation can correctly roll back to the branch used in the previous drawing.
Lengthen Optimization
The optimization of the Lengthen function provides more practical measurement and modification options to help users complete drawing tasks more efficiently and flexibly. The specific optimizations are as follows:
Support the measurement of ellipses to get accurate ellipse circumference.
Support the measurement of elliptical arcs and get the circumference of elliptical arcs. In addition, the user can modify the length of the elliptical arc by specifying the length, angle, percentage of length, and by specifying the total length or absolute value of the total angle. These new options provide users with more flexibility and control, making editing the length of elliptical arcs easier and more precise.
Support the function of shortening the length of the spline curve. The length of the spline can be shortened by specifying a negative length, a length percentage, or a total length, which makes it easier for users to adjust the length of the spline.
When multiple objects are selected, the length values of multiple objects can be measured or modified.
PDF Import Optimization
When importing PDF files, it now supports importing the layers from the PDF files.
Grips for setting viewport scale in layout
Custom grips are added in layout viewports, allowing for the rapid configuration of viewport scales.
Ακόμα θα βρείτε ότι και στο ZWCAD 2024
• Flexiblock: Similar to AutoCAD® dynamic blocks, Flexiblock empowers you to freely change block shapes using parameters and actions, eliminating the need for multiple blocks.
• Efficiency Improvement : Through multi-threaded optimization, hardware acceleration, and incremental saving, ZWCAD 2024 allows you to open, view, edit, and save files with lightning-fast speed and seamless performance.
• Point Cloud : Read and process point cloud data in popular formats like rcs and rcp. Adjust the display settings, extract section planes, manage complex point cloud easily with the Point Cloud Manager.
• Mtext Improvement : With automated tools such as Auto-Numbering, Dynamic Columns, and Spelling Check, editing multiline text (Mtext) becomes as intuitive as editing text in Microsoft® Word.
Ακόμα θα βρείτε ότι και στο ZWCAD 2023
Efficient:
• View, access, manage, and plot multiple drawings in Sheet Set Manager
• Satisfy various needs with more powerful Table Tool
• Faster in operations like Select, Delete, Pan, Zoom and 3D Render
User-friendly:
• Change a 3D entity's shape easily using grips
• Find whatever needed within seconds with new Tooltip
• Choose Object Snap type easily on Quick Menu
• Check if the selected font can replace the lost font in Preview Window
Connected:
• Compatible with 3D mouse
• Export EPS files easily
• Do more complex work with enhanced Calculator
Ακόμα θα βρείτε ότι και στο ZWCAD 2022
✓ Associative Array: Form and adjust rectangular, path, or polar arrays flexibly.
✓ CAD Standards: Create .dws files and check & fix nonstandard styles accordingly.
✓ Data Link: Link with external tables for bidirectional and synchronized data update.
✓ Plot Transparency: Objects, layers, etc. with transparency effects can be plotted.
✓ IFC Import: Import IFC files, view models, and manage entities with the IFC structure panel.
✓ Flatshot: Create a 2D version of 3D objects conveniently, avoiding drawing conversion.
Ακόμα θα βρείτε ότι και στο ZWCAD 2021
Ταχύτερη δημιουργία και καλύτερη απεικόνιση χάρη στην βελτιωμένη γραφική μηχανή του:
✓ Το άνοιγμα σχεδίων στο ZWCAD 2021 είναι 30% ταχύτερο από την προηγούμενη έκδοση
✓ Η απεικόνιση και τα εφέ έχουν βελτιωθεί, ακόμα και σε 4Κ αναλύσεις
Νέες λειτουργίες για αυξημένη παραγωγικότητα:
✓ Η διαφάνεια των objects, layers, κλπ. είναι μεταβλητή για καθαρότερη εμφάνιση των σχεδίων
✓ Διαχείριση όλων των Xrefs με ένα manager
✓ Η εντολή CLIP σου επιτρέπει να χρησιμοποιείς όλες τις λειτουργίες όπως π.χ. Invert XClip
✓ Είναι διαθέσιμες Table και field formulas για εύκολους υπολογισμούς
✓ Μπορούν να συνυπάρξουν διαφορετικά viewport layers σε κάθε viewport
