Τι νέο θα βρείτε στο ZWCAD 2024

Flexiblock
Similar to AutoCAD® dynamic blocks, Flexiblock empowers you to freely change block shapes using parameters and actions, eliminating the need for multiple blocks.
Stacks Image 490
Point Cloud
Read and process point cloud data in popular formats like rcs and rcp. Adjust the display settings, extract section planes, manage complex point cloud easily with the Point Cloud Manager.
Stacks Image 492
Efficiency Improvement
Through multi-threaded optimization, hardware acceleration, and incremental saving, ZWCAD 2024 allows you to open, view, edit, and save files with lightning-fast speed and seamless performance.
Stacks Image 494
Mtext Improvement
With automated tools such as Auto-Numbering, Dynamic Columns, and Spelling Check, editing multiline text (Mtext) becomes as intuitive as editing text in Microsoft® Word.
Stacks Image 526

Τι νέο υπήρχε στο ZWCAD 2023 SP2

Lasso Selection
Lasso selection is a new way to select objects. Compared with the traditional way of selecting objects, the lasso selection can create an irregular selection range to select multiple objects more flexibly.
As shown in the example in the figure below, if users choose the traditional selection mode, it is impossible to select four identical plants at the same time. Using the lasso selection, Users can freely create an irregular selection area to successfully select objects.
Stacks Image 514
There are 3 modes for lasso selection, “Window”, “Fence” and “Crossing”. Users can switch the mode by pressing the "Space” button during selection. Meanwhile, lasso selection supports the preview effect. When the user selects an object, the selected objects will be highlighted.
Stacks Image 518
Stacks Image 520
When the user needs to select multiple objects in a large and complex drawing, the lasso selection can be used to select objects more freely and flexibly.
Advanced Ordinate Dimension
Professionals from various industries need to use ordinate dimensions when they are drawing, but the existing ordinate dimensioning function has only one style, an inappropriate layout, and weak practicability. The coordinate dimension created by the advanced ordinate dimension function has better style, which greatly saves more space in the drawing than the existing dimensions. It makes the drawing look neater, and users can read the information more clearly.
Stacks Image 496
To meet the needs of ordinate dimensions in different design scenarios, we also provide a wealth of styles for designers to choose from. Designers can modify the dimension’s arrow shape, text style, prefix style, and so on. In addition, it also provides the ability to create dimensions in different coordinate systems.
Stacks Image 498
When designers need to add a large number of ordinate dimensions, they can create ordinate dimensions in batches. Currently, batch ordinate dimension can be used in three types of objects: "polyline", "circle" and "block reference". The dimensions data on the drawing can also be exported to a notepad, which is convenient for data storage and reuse.
Stacks Image 500

Τι νέο υπήρχε στο ZWCAD 2023 SP1

Hatch Upgrade: Δουλέψτε πιο αποδοτικά με real time preview, αυτόματο contextual menu με κλικ σε ένα υπάρχον hatch. Εύκολη επιλογή των set origin και set boundary, με δεξί κλικ πάνω στο hatch.

Import Multiple PDF pages: Μέχρι τώρα μπορούσατε να εισάγετε μια σελίδα PDF. Τώρα επιλέγετε και εισάγεται όσες σελίδες θέλετε και κερδίζετε χρόνο.

Stacks Image 445

Collect Mleaders: Όταν το σχέδιο είναι πολύπλοκο και πυκνό καλύτερα από πολλά multireaders είναι να χρησιμοποιήσετε την νέα εντολή Mleadercollect. Με αυτό τον τρόπο τους οργανώνετε όλους σε ένα κύριο μπλοκ για καλύτερο αισθητικό αποτέλεσμα και ευκολότερες μετατροπές.

Stacks Image 451

Cloud Documents: Τώρα πολλοί χρήστες μπορούν να συγχρονίζουν παράλληλα τα τοπικά σχέδια τους αυτόματα από τα πηγαία που βρίσκονται σε μια αξιόπιστη cloud υπηρεσία

Stacks Image 453

Τι νέο υπήρχε στο ZWCAD 2023

Ταχύτητα: Δουλέψτε με Select, Delete, Pan, Zoom και 3D Render ακόμα πιο λειτουργικά και ταχύτατα. Συγκριτικά με τις προηγούμενες εκδόσεις, επιλέξτε 8 φορές γρηγορότερα πολλαπλά αντικείμενα και σβήστε τα 5 φορές πιο γρήγορα.

User friendly & 3D functions: Ακόμα δυνατότερες λειτουργίες στην τρισδιάστατη σχεδίαση.

Stacks Image 435

Connected: Σύνδεση με διαφορετικές εφαρμογές, προγράμματα και εξοπλισμό όπως 3D mouse me 3D connextion(R). Οι χρήστες μπορούν να κάνουν pan, rotate και pan/ zoom σε ένα 3D αντικείμενο με χρήση του 3D mouse.

Efficient, User-friendly, Connected - an Ultimate 2D CAD Solution: Δουλέψτε εύκολα με πολλαπλά σχέδια με το Sheet Set Manager. Χρησιμοποιήστε τις νέες δυνατότητες δημιουργίας και μεταβολής πινάκων στα σχέδια με το Match Cell του Block Insertion. Σώστε ένα πίνακα σαν template για μελλοντική χρήση.

Τι νέο υπήρχε στο ZWCAD 2022 SP2 (01/22)

Η ταχύτητα και η φιλικότητα αυτής της έκδοσης είναι ακόμα καλύτερη.
New Data Types for Tables: Περισσότερα data types of table cells είναι διαθέσιμα και οι συναφείς λειτουργίες έχουν βελτιστοποιηθεί.
Enhanced Smart Plot: The output file name can be customized and different paper sizes can be plotted at the same time.
Smart Voice—Convert to Text: Τα Voice messages που δημιουργούνται με το Smart Voice, μπορούν να μετατραπούν σε κείμενα.
Transparent Command: Υπό δυναμική εισαγωγή, μια transparent εντολή μπορεί να εκτελεστεί εντός μιας άλλης τρέχουσας εντολής.

Τι νέο υπήρχε στο ZWCAD 2022 SP1 (09/21)

Newly Added ArcGIS Module Τώρα μπορεί να εισαχθεί ένας χάρτης με το δικό του σύστημα συντεταγμένων ή να γίνει μετατροπή του συστήματος συντεταγμένων, κλπ.

Τι νέο υπήρχε στο ZWCAD 2022

Associative Array: Μορφοποίησε και διαμόρφωσε rectangular, path, ή polar arrays με ευκολία.

CAD Standards: Δημιούργησε αρχεία .dws και έλεγξε & διαμόρφωσε κατάλληλα nonstandard styles.

Data Link: Σύνδεση με εξωτερικά tables για bidirectional και synchronized data update.

Plot Transparency: Objects, layers, κλπ με transparency effects μπορούν να εκτυπωθούν.

IFC Import: Εισαγωγή αρχείων IFC, εμφάνιση των μοντέλων στο σχέδιο και διαχείριση των entities μέσα από το IFC structure panel.

Flatshot: Δημιούργησε εύκολα μια 2D έκδοση τρισδιάστατων αντικειμένων, αποφεύγοντας επίπονη σχεδιαστική εργασία.

Τι νέο υπήρχε στο ZWCAD 2021

Ταχύτερη δημιουργία και καλύτερη απεικόνιση χάρη στην βελτιωμένη γραφική μηχανή του.

Νέες λειτουργίες για αυξημένη παραγωγικότητα.

Το άνοιγμα σχεδίων στο ZWCAD 2021 είναι 30% ταχύτερο από την προηγούμενη έκδοση

Η απεικόνιση και τα εφέ έχουν βελτιωθεί, ακόμα και σε 4Κ αναλύσεις

Η διαφάνεια των objects, layers, κλπ. είναι μεταβλητή για καθαρότερη εμφάνιση των σχεδίων

Διαχείριση όλων των Xrefs με ένα manager

Η εντολή CLIP σου επιτρέπει να χρησιμοποιείς όλες τις λειτουργίες όπως π.χ. Invert XClip

Είναι διαθέσιμες Table και field formulas για εύκολους υπολογισμούς

Μπορούν να συνυπάρξουν διαφορετικά viewport layers σε κάθε viewport

Stacks Image 95
Stacks Image 10
F.A.Q
People also ask:

  1. How much does ZWCAD cost? ZWCAD is a powerful CAD software with DWG capabilities. ZWCAD has three editions and prices:
  • ZWCAD Standard that costs 699 euro plus VAT 24%
  • ZWCAD Professional that costs 899 euro plus VAT 24%
  • ZWCAD Mechanical that costs 1199 euro plus VAT 24%
  1. Is ZWCAD compatible with Mac? Unfortunately no, but you could run ZWCAD in a windows environment emulation inside MacOS
  2. What is ZWCAD MFG? This is the ZWCAD version with many additional menu about mechanical designs. It includes the ZWCAD Pro menu and capabilities inside.
  3. What is ZWCAD 2024? This is the newest version of the ZWCAD software that currently has released, all new SP updates will be free of charge for the current customers of ZWCAD 2024
